Casun Nema 8 Lead Screw Stepper Motor TR5×2 (P1)
5.4V, 38mm Body, High Precision 32mN.m for Beauty Equipment
The Casun Nema 8 Lead Screw Stepper Motor features an integrated TR5×2 (P1) threaded shaft, delivering precise linear motion in a remarkably compact 38mm body. Designed specifically for beauty and aesthetic equipment, this high-precision motor combines 32mN.m torque with smooth, reliable performance for delicate applications.
Key Features
- Bipolar or unipolar versions available
- Hybrid stepper construction
- Available in single- or double-shaft versions
- CE and RoHS approved
- Customizations on request
Dimensions
Motor Specifications
| Step Angle | 1.8° |
|---|
| Frame Size | 38 mm |
|---|
| Number of Phase | 2 Phase |
|---|
| Rated Current | 0.6 Amp |
|---|
| Holding Torque | 32 mN.m |
|---|
| Resistance | 9 ohm |
|---|
| Inductance | 3.2 mH |
|---|
| Rotor Inertia | 3.5 g.cm² |
|---|
| Motor Weight | 0.08 kg |
|---|
| Connection | Bipolar |
|---|
Operating Specifications
Motor
Step Angle: 1.8°
Maximum Temperature: 80°C maximum
Ambient Temperature: -20°C to 50°C
Storage Temperature: -20°C to 100°C
Humidity Range: 85% or less, non-condensing
Magnet Wire Insulation: Class B 130°C
Insulation Resistance: 100M Ohm at 500 VDC
Dielectric Strength: 500 VDC for 1 min
Encoder
Voltage: 5V
Output: A + A - B + B - Z + Z -
Submodels
Customization Options
If our standard motor cannot meet your needs, we can customize the motor according to your requirements.
Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.
Available Options
Encoder
Brake
Gearbox
Shaft
